Happy New Year !! Thanks for your attention on  ElecFreaks in the new year. We were  always working on Flower ProtoBoard Series last month. Many people suggest us to  add SOIC support, such as Foxx D'Gamma said: support SMD and SOIC layouts for component adapters. Perhaps a PCB that will line up with the legs of a SOIC Chip but break away and line up with the pads of a Flower protoboard so you can lay the two on top of your board and do a quick solder-tack to get it in place and electrically connected to the board. So from now on, we will provide two color of Flower-SOIC ProtoBoard-MEGA shield(default Green).  It's support SOIC-SOIC28. Green Flower ProtoBoard

Black Flower ProtoBoard

Features

  • Flower-shaped pad
  • Arduino MEGA compatible
  • Standard 2.54mm(100mil) spaced holes
  • 1mm Hole size
  • Black/Green PCB
  • Easy to use point-to-point wiring, need less solder

 Package List:

  • 1 x Flower-SOIC ProtoBoard-MEGA shield
  • 2 x 2.54mm 40Pin Male Header
  • 1 x 2.54mm 2X40Pin Male Header

  Some suggestion for SOIC Kilian Singer said:

It would be great to be able to divide the pad to allow for soic smd device soldering.

Victor Sluiter said:

I would really like to see some protoboard with your system, combined with 1.27mm pitch pads for SOIC soldering. I always cut islands in halves to accomodate SOIC or SOT23 housings, you seem to be able to turn solder frustration to new products....

Foxx D'Gamma said: I do a lot of surface mount work these days and in time perhaps I can suggest ideas for new products, like SMD and SOIC layouts for component adapters. Perhaps a PCB that will line up with the legs of a SOIC Chip but break away and line up with the pads of a Flower protoboard so you can lay the two on top of your board and do a quick solder-tack to get it in place and electrically connected to the board. You can call it a "LillyPad" since it sits on top of the flowerboard like a lillypad sits on top of a pond. ......

So , if you have any idea for Flower ProtoBoard Series or improve protoboard,  please share with us. we are looking forward to you.
